Double rail double chuck net drawing machine

HUAJIN supply high quality Double rail double chuck net drawing machine which used in screen printing for small and larger printing object.

Tips:

1. During the use of the cylinder, be sure to add oil to the screw (spindle) every day to reduce friction.
2. Before and after the use of the handwheel, be sure to add oil to each adjusting nut and screw.
3. At the oil filling position, pull the rocker back slightly and turn the handwheel to find the oil filling hole.
4. Please open the clamp when not in use to avoid affecting the elasticity of the bead due to long time.
5. If the machine is not used for a long time, please cut off the power supply and gas source at the same time, and do a good job of rust prevention on the metal surface.
6. It is strictly forbidden to stack heavy objects on the movable rod of the whole machine, so as to avoid the deformation of the movable rod and cannot be used.
7. When using, please stretch the Mesh first in the transverse direction, and then in the longitudinal direction, so as to achieve the required tension.
8. Before stretching the net, you must first fix the block screw at the bottom of the movable rod to set the whole machine, and then do the stretching tension.
9. If the machine is not used for a long time, please cut off the power supply and gas source at the same time, and do a good job of rust prevention on the metal surface.
10. How to deal with the equipment after its service life expires: When the equipment has reached its service life and cannot be used any more, please unplug the power supply and handle it reasonably according to local regulations.
