Nylon Filter Mesh

Filter Screen Mesh

Nylon Mesh is a type of Mesh with plain woven by 100% nylon mono filament yarn With its good performance,

Key Features

High tensile strength & dimensional stability
Excellent chemical resistance
Uniform mesh structure for consistent printing
Long service life (5000+ print cycles)

Release Date

2020-07-23 19:36:01

Inquire Now View Specs

Product Description

Nylon Mesh is a type of Mesh with plain woven by 100% nylon mono filament yarn.

With its good performance, Anti resistance, Anti acid resistance, corrosion resistance, stable structure, Nylon Mesh widely used in filtration, separation and sifting industry, such as air filtration, liquid filtration, oil filtration, flour milling, grains milling, milk filtration and other juice filtration in food industry etc.

Also, it could be make into different type, nylon bags, tubes, belt etc. used in Agricultural industry, fish farming, Shrimp farming, Seaweed farming, etc. huajin can produce the following specifications:

Opening: 5micron -1200micron
Width: 100cm-258cm
Color: White
Weaving: Plain Weave/Twill Weave

Technical Specifications

huajin 100% Monofilament Nylon Mesh Specification Sheet
MESH Type Mesh/cm	MESH COUNT Mesh/inch	THREAD DIAMETER μm	MESH OPENING μm	WEAVING PW/TW	OPEN AREA %	THICKNESS μm	WEIGHT g/m²
PA4	10	600	1900	PW	60	1100	251
PA5	13	500	1500	PW	55	1000	270
PA 6	15	400	1254	PW	57	800	199
PA7	18	350	1068	PW	56	700	183
PA8	20	350	891	PW	51	700	203
PA9	23	250	861	PW	59	500	125
PA9	23	300	811	PW	52	570	208
PA10	25	250	750	PW	55	500	130
PA10	25	300	700	PW	48	600	187
PA12	30	250	583	PW	48	500	156
PA12	30	300	533	PW	40	600	224
PA14	35	300	414	PW	33	510	261
PA16	41	200	425	PW	45	340	136
PA20	50	150	350	PW	48	255	93
PA20	50	200	300	PW	35	340	166
PA24	60	150	267	PW	40	255	112
PA28	71	120	237	PW	43	204	84
PA30	76	120	213	PW	40	204	91
PA32	81	100	213	PW	45	170	66
PA32	81	120	193	PW	40	204	91
PA36	91	100	178	PW	40	170	75
PA40	100	100	150	PW	35	170	83
PA43	110	80	153	PW	42	136	58
PA48	122	80	128	PW	37	136	64
PA56	142	60	119	PW	43	102	42
PA64	163	60	96	PW	37	102	49
PA72	183	50	89	PW	40	85	38
PA80	203	50	75	PW	35	85	42
PA90	229	43	69	PW	39	71	33
PA100	254	43	57	PW	31	80	37
PA110	279	43	48	PW	25	76	41
PA120	305	43	40	PW	21	80	45
PA130	330	35	42	PW	17	73	51
PA140	355	35	37	PW	22	60	36
PA157	399	43	25	TW	21	58	33
PA180	457	39	20	TW	***	***	***
PA200	508	39	15	TW	10.2	57	31
PA220	559	39	10	TW	***	***	***
PA240	600	39	5	TW	***	***	***
Normal width: 115cm, 127cm, 145cm, 150cm, 160cm, 184cm, Max width 258cm
Remark: 1. PW: Plain weave TW: Twill weave 2. The above are theoretic data for reference only. Thickness error range±5%; Mesh Opening & Open Area & Weight only slight error according to actual data. 3. Special size are customized

* Custom specifications available upon request. Contact our sales team for detailed technical data sheets.
